NAFEMS Benchmark Challenge - NBC07 Solution Modelling Beam Members with Finite Elements


The reader is asked to investigate the two beam problems presented in figure 1 using the various beam elements offered in their finite element system (including and excluding shear deformation) with the aim of providing accurate results for the moment reactions, the maximum displacement and the maximum bending moment. Evidence of solution verification should be provided in terms of the convergence of the quantities of interest with mesh refinement and a prediction of the minimum number of elements required to obtain a accuracy of 1% in all quantities should be provided.

Document Details

Reference

BM_Jan_17_15

Authors

Ramsay. A

Language

English

Type

Magazine Article

Date

2017-01-01

Organisations

Ramsay Maunder Associates

Region

Global

 Free Download
